| Hardware Specifications |
| CPU |
CPU Model |
Intel Xeon Quad/Hexa Core processor |
| CPU Architecture |
64-bit |
| CPU Frequency |
upto 2.0 GHz |
| Memory |
|
|
| Memory Module Pre-installed |
32GB DDR4 |
| Total Memory Slots |
16 Slot |
| Memory Expandable upto |
2048 GB capacity |
| Storage |
Drive Bays |
24 |
| M.2 Drive Slots |
1 |
| Compatible Drive Type |
3.5" SATA HDD |
| 2.5" SATA HDD |
| 2.5" SATA SSD |
| Storage |
20x12TB SAS SAS 12G Business Critical 7.2K LFF |
| External Ports |
Expansion |
2x USB 3.2 Gen 2 (10Gbps) Type-A |
| Host connection ports |
1x Gigabit Ethernet (1G/100M), & 10Gb Short Range iSCSI SFP+ |
| PCIe Expansion Slots |
1x PICex1 slots, 1x PCIe x16 slots |
| for optional 10 GbE card |
| Remote hardware management controller (Out-of- band Management) |
• Dedicated management port |
| • HTML5 GUI |
| • Virtual media |
| • Agentless monitoring |
| Silicon root of trust security |
| Others |
System Fan |
3 Nos. Hot swap FAN |
| Power Supply Unit / Adapter |
Dual hot plug redundant power supplies. Input 110~240V AC 50Hz. |
| Redundant power supply |
Yes |
| Service LED Indicator |
Yes |
| Certification |
FCC, CE, ROHS, BIS, ISO |
| Warranty |
5-years comprehensive onsite Next Business Day |
| Operation |
Power Consumption |
200W (Operation); |
|
180W (Disk Hibernation) |
| Weight |
Weight |
Weight13 (kg) Package Contents |
| Storage and OS |
|
1x250GB SSD for OS, OEM OS installed |
| Software & Features |
| General Specifications |
Supported OS |
Windows 7, 8, 10, 11, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022, Server 2025 |
| macOS, UNIX, and Linux |
| Supported Languages |
English |
| Supported Browsers |
Firefox |
| Chrome |
| Safari |
| Microsoft Edge |
| Network |
Network Protocols |
SMB, AFP, NFS, FTP, Rsync, SSH, iSCSI, SNMP |
| Connection and transmission |
TCP/IP (IPv4 & IPv6) |
| Network Failover |
| VLAN |
| File Management & Sharing |
File System |
Internal Disk: ZFS |
| External Disk: FAT32, NTFS, EXT3, EXT4 |
| Storage management |
Volume |
Support Multiple Volumes with Spare Drives |
| Volume Type: Single, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 |
| Support for Online RAID Capacity Expansion |
| MyArchive |
Supports snapshots |
| Disk Management |
Scheduled Bad Block Scans |
| Scheduled S.M.A.R.T Scans |
| Access & Security |
Access Control |
Maximum Number of Users: 16384 |
| Maximum Number of Groups: 512 |
| Maximum Number of Shared Folders: 512 |
| Supports Windows Active Directory |
| Supports Windows Active Directory / LDAP |
| Security |
AES 256-Bit Encryption |
| Firewall: Prevent Unauthorized Access |
| Alert Notifications: E-mail |
| Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH |
| RAID Scrubbing: detects the integrity and consistency of RAID 5 and RAID 6 drive data. |
Intel Xeon CPU
Cost Effective
High Performance
Capable of running 24x7
